9424200994 Rev N
Loss of Excitation – Impedance Based
(40Z) Test
Functional testing is a way to assess this protection system's suitability for your application. Functional
testing goes beyond the more basic tests found in acceptance testing, but lacks the detailed function
testing that is part of the commissioning process.
Test each of the following functions to verify that this BE1-11g measures accurately, is within specified
tolerances, and operates correctly. These tests are also suitable for assisting in systematic
troubleshooting in the event that an operation is questioned. Revisiting the test of a specific function can
help verify whether the BE1-11g is operating within specified tolerances. For further assistance, contact
Basler Electric, Technical Sales Support.
Refer to the
Terminals and Connectors
Reset all targets prior to each test by navigating to the Metering > Status > Targets screen and pressing
the front-panel Reset key. Enter the appropriate username and password if prompted. Clear all logic prior
to each test by using the Settings Explorer in BESTCOMSPlus® to open the BESTlogic™Plus
Programmable Logic screen and click the Clear button located on the toolbar. After new BESTlogicPlus
settings are made, click the Save button located on the toolbar to compile BESTlogicPlus. Upload
BESTlogicPlus settings by selecting Upload Logic to Device from the Communication pull-down menu.
Operational settings can be sent by selecting Upload Settings to Device from the Communication pull-
down menu or by clicking the Send Settings button on the toolbar.
The actual operating time of an output contact is equal to the recognition time plus the time delay setting
(accuracy) plus 6 milliseconds. Output contact operating time depends upon the type of test set used and
its operating characteristics.
A Functional Test Report is included at the end of this chapter. It should be used to record the results and
verify pickup and timing accuracy.
Refer to the
Loss of Excitation - Impedance Based (40Z) Protection
function.
Functional Test Procedure
Pickup Verification
Step 1:
Use BESTCOMSPlus to send the operational settings in Table 232 to the BE1-11g. Reset all
targets.
Setting
Nominal Phase
Voltage
Nominal Phase
Current
Nominal Auxiliary
Voltage
Phase CT 1 Ratio
BE1-11g
chapter for terminal locations and connections.
Table 232. Operational Settings
Value
BESTCOMSPlus Screen
69.3 V
System Parameters, Power System
5 A
System Parameters, Power System
69.3 V
System Parameters, Power System
1
System Parameters, Sensing
Transformers
chapter for more information on this
Loss of Excitation – Impedance Based (40Z) Test
505
Description
Sets the nominal
secondary sensing
voltage to 69.3 V
Sets the nominal
secondary sensing
current to 5 A
Sets the nominal
secondary auxiliary
voltage to 69.3 V
Sets the phase CT ratio
to 1
