Basler BE1-11g Instruction Manual page 477

9424200994 Rev N
4 5.0
4 5.0
4 9.9
4 9.9
4 9.9
Timing Verification (IG Mode, SEF)
Time Dial Range = 0.0 to 9.9
Timing Accuracy = ±5% or ±1½ cycles, whichever is greater
Step Time Dial Time Curve
4 0.5
4 0.5
4 0.5
4 5.0
4 5.0
4 5.0
4 9.9
4 9.9
4 9.9
BE1-11g
I2 0.50 A
I2 2.50 A
I2 0.20 A
I2 0.50 A
I2 2.50 A
Applied Current
I2 0.20 A
I2 0.50 A
I2 0.80 A
I2 0.20 A
I2 0.50 A
I2 0.80 A
I2 0.20 A
I2 0.50 A
I2 0.80 A
1.798 sec
0.944 sec
8.300 sec
3.535 sec
1.844 sec
Low Actual Timing
0.444 sec
0.190 sec
0.149 sec
4.204 sec
1.798 sec
1.401 sec
8.300 sec
3.535 sec
2.674 sec
Inverse Overcurrent (51) Test
465
1.988 sec P / F
1.044 sec P / F
9.173 sec P / F
3.907 sec P / F
2.038 sec P / F
High Pass/Fail
0.491 sec P / F
0.240 sec P / F
0.197 sec P / F
4.647 sec P / F
1.988 sec P / F
1.548 sec P / F
9.173 sec P / F
3.907 sec P / F
3.111 sec P / F
