BRAKE PAD REPLACEMENT

Remove the brake pad mounting pin.
Remove the brake pads.
Do not operate the brake pedal during or after brake
pad removal.
Replace the brake pads as a set, otherwise braking
performance will be adversely affected.
Install the new brake pads.
Make sure that the brake pad is properly engaged with
the guide plate as shown in the photograph.
Tighten the brake pad mounting pin to the specified torque.
Brake pad mounting pin: 18 N·m (1.8 kgf-m, 13.0 lb-ft)
NOTE:
After replacing the brake pads, pump the brake pedal a few times
to check for proper brake operation and then check the brake
fluid level.
CHASSIS 6-55
