8-28 SERVICING INFORMATION
CLUTCH
ITEM
Clutch lever play
Clutch drive plate thickness
(No. 1 & No. 2)
Clutch drive plate claw width
(No. 1 & No. 2)
Clutch drive plate distortion
Clutch spring free length
TRANSMISSION + DRIVE CHAIN
ITEM
Primary reduction ratio
Final reduction ratio
Gear ratios
Gearshift-fork-to-gearshift-fork-groove
clearance
Gearshift fork groove width
Gearshift fork thickness
Drive chain
Drive chain slack
Low
2nd
3rd
4th
Top
No. 1, No. 2
& No. 3
No. 1, No. 2
& No. 3
Type
Links
20-pitch length
STANDARD
10 – 15
(0.4 – 0.6)
2.92 – 3.08
(0.115 – 0.121)
13.7 – 13.8
(0.539 – 0.543)
—
—
STANDARD
2.960 (74/25)
3.357 (47/14)
2.285 (32/14)
1.733 (26/15)
1.375 (22/16)
1.090 (24/22)
0.863 (19/22)
0.1 – 0.3
(0.004 – 0.012)
4.8 – 4.9
(0.189 – 0.193)
4.6 – 4.7
(0.181 – 0.185)
RK520KZO
112
—
40 – 50
(1.6 – 2.0)
Unit: mm (in)
LIMIT
—
2.62
(0.103)
13.2
(0.520)
0.10
(0.004)
49.9
(1.96)
Unit: mm (in) Except ratio
LIMIT
—
—
—
—
—
—
—
0.5
(0.02)
—
—
—
—
319.4
(12.57)
—
