6-44 CHASSIS
Tighten the swingarm pivot shaft nut to the specified torque.
Pivot shaft nut: 77 N·m (7.7 kgf-m, 55.5 lb-ft)
Tighten the cushion lever mounting nut to the specified torque.
Cushion lever mounting nut:

FINAL INSPECTION AND ADJUSTMENT

After installing the rear wheel, adjust the following before riding.
Drive chain ...................................................
Tire pressure ..........................................................
100 N·m (10.0 kgf·m, 72.5 lb-ft)
2-16 to 2-17
2-22
