Chapter
2
Using the Optional Internal Rewinder
2. The bottom of the plastic paper path is shaped like a hook and the top has
a groove:
a. Hook the bottom of the paper path under the bottom edge of the front
b. Snap the groove on the paper path to the top edge of the front door.
3. Close the front door.
Loading Media
1. To load media, refer to "Loading Roll Media" on page 29 and complete
steps 1 through 10.
44
door.
Rewinder
Release Lever
Rewinder
