Chapter 2
Loading Media and Ribbon
IMPORTANT
Do not attach the ribbon to the ribbon take-up spindle without a
fiberboard take-up core installed.
5. Attach the ribbon to the ribbon take-up core on the ribbon take-up spindle
using the adhesive on the ribbon leader.
6. Manually rotate the spindle clockwise until the clear leader has passed
the printhead.
7. Close the pivoting deck and rotate the deck lock lever fully
counterclockwise.
8. Verify that Print Mode (in the QUICK SETUP menu) is set for Transfer.
See "QUICK SETUP" on page 95 for more information.
9. If you have not run an Auto Calibrate with this media and ribbon, do so
now. See "Running Auto Calibrate" on page 60.
10. Press the FEED key once to verify that the media and ribbon advance.
11. Press the PAUSE key to place the printer online.
12. Close the printer media cover if the rewinder is not needed.
42
Media Cover
Media and Ribbon
Loading Instructions
Ribbon
Take-up Core
Ribbon
Take-up Spindle
