Serial Port - Printronix T5204R Administrator's Manual

SERIAL PORT

SERIAL PORT
(from page 91)
Port Type Baud Rate
RS 232* 9600 BAUD*
RS 422 19200 BAUD
Disable 38400 BAUD
57600 BAUD
115200 BAUD
600 BAUD
1200 BAUD
2400 BAUD
4800 BAUD
Buffer Size Trickle
in K Time
16* 1/4 sec*
1-16 1/2 sec
32 1 sec
64 2 sec
4 sec
8 sec
16 sec
Off
Poll
Character Reponse
0 ms*
00 Hex*
0-30 ms
00-FF Hex
Offline
Process
Disable*
Enable
Word
Length
8*
7
Timeout
10 sec.* Disable*
1-60 sec. Enable
Poll Idle
Response
Disable*
Enable
Stop Parity
Bits
1* None*
2 Odd
Even
Mark
Sense
Report Data Term
Status Ready
True*
On-Line and BNF
Off-Line or BF
On-Line
False
One Char Printer
Enquiry Status
Disable* Disable*
Enable ENQ/STX
ENQ
Notes:
* = Factory Default
Italicized items are available only when you enable
Admin User (in the PRINTER CONTROL menu).
Data
Protocol
XON/XOFF*
ETX/ACK
ACK/NAK
Series1 1 Char
Series1 2 Char
ENQ/ACK
DTR
Request to
Send
On-Line and BNF*
Off-Line or BF
On-Line
False
True
Framing
Errors
Enable*
Disable
