Chapter 3
MEDIA CONTROL
MEDIA
CONTROL
(from page 107)
Peel-Off Continuous
1
Mode Mode
Fast* Standard*
Standard Tear-Off
Tear-Strip Full
Cut Strip
TOF Adjust
3
0.00 to 0.40 inches Standard*
Forward Only
Notes:
* = Factory Default
Italicized items are available only when Admin User is set to Enable (in the PRINTER CONTROL menu).
1
The Peel-Off option under Media Handling must be enabled for this menu to function.
2
The Continuous option under Media Handling must be enabled for this menu to function.
3
In increments of 0.01 inch.
4
Available when a 203 DPI printhead is installed.
5
Available when a 300 DPI printhead is installed.

MEDIA CONTROL Submenus

Print Intensity
This option specifies the level of thermal energy from the printhead to be used
for the type of media and ribbon installed.
Large numbers imply more heat (thermal energy) to be applied for each dot.
This has a significant effect on print quality. The print intensity and speed
must match the media and ribbon type to obtain the best possible print quality
and barcode grades.
The range is from -15 to +15.
The factory default is -3.
108
TOF Detect
2
Fault
3 Labels*
9 Labels
1 Label
Ribbon Reverse
1
Calibrate Speed
2 ips*
1 to 6 ips
Ticket Save TOF Adjust
Mode Mode
Disable* Disable*
Enable Enable
Vertical DPI
Adj
4
203*
195 to 210
5
300*
290 to 310
