Upper
Sensor
Visible Red Beam
Lower Sensor
11. Slide the upper sensor directly over the lower sensor.
Guide Notch
12. Align the left (inside) edge of the media with the guide notch located on
the front edge of the tear bar.
Upper Sensor
Handle
Media Guard
Opening
Media
(left edge)
Loading Roll Media
33
