Printronix T5204R Administrator's Manual page 314

Chapter 6
Diagnostics for E0xx, Bad NVM, or ILL NVM Errors
Table 18. LCD Message Troubleshooting (continued)
Displayed Message
DOWNLOADING TO
VALIDATOR
E00 EXE @ ADDR0
E01A TYPE 0x40
E01B TYPE 0x60
E02 MACHINE CHK
E03A DSI HASH L
E03B DSI HASH S
E03C DSI BAT PL
E03D DSI BAT PS
E03E DSI CXIWX
E03F DSI CXOWX
E03G DSI ECXIWX
E03H DSI ECXOWX
E04A ISI NO TRA
E04B ISI DIRECT
E04C ISI PROTEC
E06 NOT ALIGNED
E07 ILLEGAL INS
E08 FLOATINGPNT
E-NET INIT
E-NET READY
314
Can User
Explanation
Correct?
Yes Normal message when
the printer is
downloading validator
firmware.
Yes An illegal or
unsupported
instruction was
attempted in the
application program.
Yes An illegal or
unsupported
instruction was
attempted in the
application program.
Yes Ethernet is initializing.
Yes Ethernet has finished
initializing.
Solution
No action required.
NOTE: The validator software
update can be verified in the
F/W Revision menu option of
the VALIDATOR menu. Shown
as: Example X326
1. Cycle Power. Run the print
job again. If the message
appears, load the latest
emulation software.
2. Cycle power. Run the print
job again. If the message
appears, record the display
message and follow the
instructions for
"Diagnostics for E0xx, Bad
NVM, or ILL NVM Errors"
on page 299.
3. Contact your authorized
customer service
representative.
1. Cycle Power. Run the print
job again. If the message
appears, load the latest
emulation software.
2. Cycle power. Run the print
job again. If the message
appears, record the display
message and follow the
instructions for
"Diagnostics for E0xx, Bad
NVM, or ILL NVM Errors"
on page 299.
3. Contact your authorized
customer service
representative.
No action required.
No action required.
