2.5 Configuring Radio Parameters

The AP automatically configures most radio parameters. Only advanced
users, Symbol trained users or Symbol representatives should adjust the
radio parameters for the AP , the options in the RF Configuration screen or
fine-tune the radio and WLAP functions.
1. Select Set RF Configuration from the Main Menu to display:
CCA Mode
AP-4121 model access point RF Configuration screen is slightly different from
the AP-4111 model access point RF Configuration screen.
AP-4100 Series Access Point Product Reference Guide
Symbol Access Point
.DTIM Interval
.BC/MC Q Max
.Max Retries (d)
.Max Retries (v)
.Multicast Mask (d) 09000E00 hex
.Multicast Mask (v) 01005E00 hex
.Beacon Interval
.Accept Broadcast ESSID Enabled
.MU Inactivity Timeout
.Rate Control
11 Mb/s
5.5 Mb/s
2 Mb/s
1 Mb/s
.RTS Threshold
.Extended Range
OK-[CR]
The frequency of DTIM packets as a multiple of TIM packets. Range(1..255)
and
CCA Energy Threshold
RF Configuration
10 WLAP Mode
10
15 WLAP Priority
5 WLAP Manual BSS ID 00:00:00:00:00:00
WLAP Hello Time
100 K-us WLAP Max Age
WLAP Forward Delay
60 min. WLAP MU Table Aging Time
Optional .Shared Key
Optional .Key Width
Optional .Encryption Key ID
Required .Encryption Key Maintenance
2347 bytes .BlueTooth Coexistence 0 ms
0 mi.
.Short RF Preamble
.Tx Power Control
Save-[F1] Save All APs-[F2]
are not user configurable parameters. The
Configuring the AP
Disabled
8000 hex
20
100
5
240 min.
Enabled
128 bit
1
Disabled
Full
Cancel-[ESC]
75
