Configuring the AP
7. Press ESC to refresh the display. The AP displays the Main Menu.
2.2.4
Navigating the UI Using a Web Browser
Refer to the online help file for information on Web Browser navigation and
basic functionality. For file download instructions and the associated file(s)
refer to the Web page:
(http://www.symbol.com/services/downloads/download_spec24.html) and
select
and....
2.3
Access Point Installation
The AP UI includes an AP Installation screen to set basic parameters for a
Spectrum24 network. These parameters include designating a gateway
address that provides the ability to forward messages across routers on the
wired Ethernet.
To install an AP:
1. From the Main Menu select
2. Enter the default password (unless the password has been changed):
56
Symbol Access Point
Show System Summary
Show Interface Statistics
Show Forwarding Counts
Show Mobile Units
Show Known APs
Show Ethernet Statistics
Show RF Statistics
Show Misc. Statistics
Show Event History
Enter Admin Mode
Spectrum24® – 11 Mbps DS Firmware, Software, Drivers, Tools
Enter System Password:
Symbol
MAIN MENU
AP Installation
Special Functions
Set System Configuration
Set RF Configuration
Set Access Control List
Set Address Filtering
Set Type Filtering
Set SNMP Configuration
Set Event Logging Configuration
Enter Admin Mode
AP-4100 Series Access Point Product Reference Guide
. The system displays
