Mobile Units - Symbol Spectrum24 AP-4100 Series Product Reference Manual

3.4

Mobile Units

Mobile Units (MU) statistics provide information on MUs associated with the
AP . The statistics include information on data sent and received, activity and
association. An MU shows only in the Home/Foreign Agent Table screens
when an MU has roamed to another AP on a different subnet. Once an MU
has roamed, the MU IP Address displays on the Home Agent Table screen of
the MU "home" AP with the IP Address of the Foreign Agent to tell the
"home" AP where to forward packets.
The MU IP Address is also shown in the Foreign Agent Table and Regular
screens of the new "foreign" AP to tell the new AP where to expect packets
from for newly associated MUs. The AP Regular screen shows the MUs
associated locally on the same subnet.
•
AP-4100 Series Access Point Product Reference Guide
Select Show Mobile Units from the Main Menu to display:
Symbol Access Point
Show System Summary
Show Interface Statistics
Show Forwarding Counts
Show Mobile Units
Show Known APs
Show Ethernet Statistics
Show RF Statistics
Show Misc. Statistics
Show Event History
Enter Admin Mode
Regular Home Agent
MAIN MENU
AP Installation
Special Functions
Set System Configuration
Set RF Configuration
Set Access Control List
Set Address Filtering
Set Type Filtering
Set SNMP Configuration
Set Event Logging Configuration
Foreign Agent
Monitoring Statistics
151
