Configuring the AP
5. Press ESC to refresh the display. The AP displays the Main Menu.
6. Refer to section 2.11.2: "Updating Using Xmodem" on page 117 to
7. Exit the communication program to terminate the session.
2.1.3

Using a Dial-Up Connection

A dial-up connection requires a straight-through cable between the modem
and the AP . The remote PC requires a modem and a communication
program (Microsoft Windows Terminal program).
See Appendix B for information on the modems supported by the AP .
1. Set
2. Attach a straight-through serial cable from the AP to the modem.
3. Verify the modem connects to the telephone line and has power.
4. From the remote terminal, start the communication program.
42
Symbol Access Point
Show System Summary
Show Interface Statistics
Show Forwarding Counts
Show Mobile Units
Show Known APs
Show Ethernet Statistics
Show RF Statistics
Show Misc. Statistics
Show Event History
Enter Admin Mode
update the AP firmware or HTML file or to section 2.2: "Navigating the
UI" on page 50.
Modem Connected
Refer to the modem documentation for information on verifying
device power.
MAIN MENU
AP Installation
Special Functions
Set System Configuration
Set RF Configuration
Set Access Control List
Set Address Filtering
Set Type Filtering
Set SNMP Configuration
Set Event Logging Configuration
to in the System Configuration screen.
Yes
