Media Types - Symbol Spectrum24 AP-4100 Series Product Reference Manual

Program the DHCP or BOOTP server to transfer these files (Kerberos security
information, HTML, firmware or network configuration files) with these
DHCP options for the specific file or information to download:
Description of DHCP Options Option Number
Firmware and HTML file
ESSID
Configuration filename
ACL filename
Kerberos enable/disable flag
KDC name
KSS name
KSS port number
When the AP receives a network configuration change or is not able to renew
the IP address lease the AP sends out an SNMP trap if SNMP is configured.
1.3.4

Media Types

The AP supports bridging between Ethernet and radio media.
The Ethernet interface fully complies with Ethernet Rev. 2 and IEEE 802.3
specifications. The AP supports 10/100Base-T wired connections. The data
transfer rate over radio waves is 11 Mbps.
The radio interface conforms to IEEE 802.11 specifications. The interface
operates at 11 Mbps using direct-sequence radio technology. The AP
supports multiple-cell operations with fast roaming between cells. With the
direct-sequence system, each cell operates independently. Each cell provides
an 11 Mbps bandwidth. Adding cells to the network provides increased
coverage area and total system capacity. The AP supports MUs operating in
Power Save Polling (PSP) mode or Continuously Aware Mode (CAM) without
user intervention.
AP-4100 Series Access Point Product Reference Guide
67 (
filenames are separated by a space)
128
129
130
131(
set to 0 for disable or 1 for enable on
the DHCP server)
132
133
134
Introduction
17
