Requirements

The minimum installation requirements for a single-cell,
peer-to-peer network:
•
•
The AP supports 10/100Base-T unshielded twisted pair (UTP) wired LAN
cabling connections. For management user interface access to the serial
connector, use a standard null-modem cable for direct serial connection.
Order a null-modem cable, part number 61383-00-0, by contacting a
Symbol sales representative.
Test and use the radio network with an MU.
4.3.1

Network Connection

Locate connectors for Ethernet and power on the back of the AP .
Ethernet configurations vary according to the environment. Determine the
Ethernet wiring to connect the AP , 10/100Base-T UTP or single cell.
The site survey determines the number of APs to install and their location.
4.3.2

10/100Base-T UTP

Use a 10/100Base-T connection for an AP attached to a wired UTP Ethernet
hub. Normal 10/100Base-T limitations apply.
To connect 10/100Base-T UTP:
1. Plug the data cable RJ-45 connector into the AP RJ-45 connector.
2. Plug the other end of the data cable into the LAN access port (possibly a
174
a power outlet
an AP antenna.
hub or wall connection).
