4.6
Mounting the AP
The AP rests on a flat surface or attaches to a wall, or any hard, flat, stable
surface. Use the standard-mounting kit provided with the Spectrum24
AP-4100 series Access Point.
Choose one of the options based on the environment
Resting flat
Attaching on the wall
4.7
Connecting the Power Adapter
The power adapter connects to the rear of the AP and to a power outlet.
1. Verify the power adapter is correct according to the country.
2. Plug the power adapter cable into the socket at the back of the AP .
3. Plug the adapter into an outlet. The AP is functional when the Status
The AP works without user intervention after setup. See the AP LED indicators
to verify that the unit operates properly.
AP-4100 Series Access Point Product Reference Guide
indicator on the front of the AP reaches a consistent flashing and the
Wireless LAN Activity indicator begins flickering. This indicates that the
AP is ready for MUs to associate with it.
Rests on the four rubber pads on the underside of
the AP . Place on a surface clear of debris and away
from traffic.
Rests on screws. Orient the AP in a downward
position on the wall so the LEDs face the floor.
Hardware Installation
177
