Introduction

Using SNMP

The AP includes SNMP agent versions accessible through an SNMP manager
application such as, HP Open View or Cabletron Spectrum MIB browser.
The SNMP agent supports SNMP versions 1 and a subset of version 2, MIB II,
the 802.11 MIB and one Symbol proprietary MIB (Management Information
Base). The SNMP agent supports read-write, read-only or disabled modes.
The AP supports traps that return to the SNMP manager when certain events
occur. The Symbol MIB is available on the Spectrum24 High Rate 11 Mbps
Wireless LAN Software CDROM or from http://www.symbol.com/services/
downloads/download_spec24.html.
Disable Kerberos Encryption to use SNMP to configure access point settings.
Increased MIB Support
The MIB (Management Information Base) has ten categories defining
what the management station needs to understand and which objects the
station manages.
36 AP-4100 Series Access Point Product Reference Guide
