TRANSMISSION

SHIFT LEVER / CABLE

1. Remove the shift knob cover

and shift knob

from the shift lever .

Remove the screws retaining the center console

using a T27 and T30 Torx driver. Remove the console

from the vehicle.

2. Remove the clip and washer retaining the shift cable

to the shift lever and disconnect the cable end from

3. Remove the retaining ring

off the mounting bracket and out from the frame.

4. Remove both bushings

service as needed.

, retaining screw

and slide the shift lever

from the shift lever and

9925723 R01 - 2015 RZR 900 Service Manual

Perform the removal steps in reverse order to install the

gear shift lever (lever, cable, console, shift knob).
