1.2.1

Options Information

The conga-IC175 is currently available in four variants.
configurations available. Check for the part number that applies to your product. This will tell you what options described in this user's guide
are available on your particular module
Table 1 conga-IC175 Variants
Part-No.
Processor
Intel ® Smart Cache
Max. Turbo Frequency
Processor Graphics
Graphics Max. Dynamic Freq
Memory (DDR4)
LVDS
DisplayPort (DP)
HDMI
Processor TDP (cTDP)
1.2.2

Optional Accessories

Table 2 Cooling/IO Shield
Accessories
conga-IC97/CSA
conga-IC97/Retention Frame
conga-IC97/CSP
conga-IC170 IO Shield - Standard Size
conga-IC170 IO Shield - Thin Size
Table 3 Memory Modules
Memory Modules
DDR4-SODIMM-2400 (4GB)
DDR4-SODIMM-2400 (8GB)
DDR4-SODIMM-2400 (16GB)
Copyright © 2017 congatec AG
This user's guide describes all of these variants. The table below show the different
052900 052901
Intel Core™ i5-7300U Intel Core™ i3-7100U
® ®
2.6 GHz Dual Core™ 2.4 GHz Dual Core™
3 MB 3 MB
3.5 GHz N.A
Intel HD Graphics 620 Intel HD Graphics 620
® ®
(GT2) (GT2)
1.1 GHz 1.0 GHz
2133 MT/s dual channel 2133 MT/s dual channel 2133 MT/s dual channel 2133 MT/s dual channel
Yes Yes
Yes Yes
Yes Yes
15 (7.5) W 15 (7.5) W
Part No. Description
052252 12 V active cooling solution with Thin Mini-ITX height (compatible with conga-IC175)
052254 Retention frame for conga-IC97/CSA (compatible with conga-IC175)
052260 Passive cooling solution with Thin Mini-ITX height (compatible with conga-IC175)
052751 IO shield for conga-IC175 Mini-ITX height
052752 IO shield for conga-IC175 with Thin Mini-ITX height
Part No. Description
068790 Certified 4 GB DDR4 SODIMM memory module with 2400 MT/s
068791 Certified 8 GB DDR4 SODIMM memory module with 2400 MT/s
068792 Certified 16 GB DDR4 SODIMM memory module with 2400 MT/s
052902 052903
Intel Celeron 3965U Intel Core™ i7-7600U
® ® ®
2.2 GHz Dual Core 2.8 GHz Dual Core™
2 MB 4 MB
N.A 3.9 GHz
Intel HD Graphics 610 Intel HD Graphics 620
® ®
(GT1) (GT2)
0.9 GHz 1.1 GHz
Yes Yes
Yes Yes
Yes Yes
15 (10) W 15 (7.5) W
ICKLm02 11/59
