1.2.2

Options Information

The conga-SMC1 is available in two variants—ARM-based and x86-based variants. The table below shows the different configurations available.
Table 2 conga-SMC1 Variants
Features
Part Number
USB
Audio Codec
1.2.3

Optional Accessories

Table 3 Cables
Cables
cab-Pico-ITX-Buttons-LED
cab-CAN-cable
cab-Pico-ITX-GPIO
cab-Pico-ITX-RS232
cab-Pico-ITX-RS422
cab-Pico-ITX-RS485
cab-Backlight ZHR-8
cab-LVDS SHDR-40V
cab-Backlight ZHR-8 51146-0600
cab-LVDS SHDR-40V FI-X30HL
cab-ThinMini-ITX-Floppy to SATA Power 14000260
SATA III cable straight/straight
SATA III cable down/straight
Copyright © 2020 congatec AG
Description
020750 020751
1 x USB OTG 2 x USB 3.0 Type A
2 x USB 3.0 Type A 2x USB 2.0 Type A
2x USB 2.0 Type A
WM8904 ultra low I2S codec ALC888S-VD 7.1 channel HDA codec
Part No. conga-SMC1
Connector
14000147 X32
14000149 X24, X25
14000151 X30, X31, X37
14000152 X26, X27, X28, X29
14000153 X26, X27
14000154 X26, X27
14000253 X19
14000254 X17
14000255 X19
14000256 X17
X8
48000029 X5
48000030 X5
Description
15 cm internal buttons and LEDs cable
15 cm CAN bus adapter cable with termination (DSUB9 male)
15 cm GPIO cable with open end
15 cm 5-wire RS232 cable adapter (DSUB9 male)
15 cm 5-wire RS422 cable adapter (DSUB9 male)
15 cm 5-wire RS485 cable adapter (DSUB9 male)
50 cm backlight cable with ZHR-8 connector and open end
50 cm, 40-pin LVDS cable with JST SHDR-40 connector and open end
50 cm backlight cable with ZHR-8 connector and Molex 51146-0600
50 cm, 40-pin LVDS cable with JST SHDR-40 and JAE FI-X30HL
20 cm Delock 85248 cable for SATA power
30 cm SATA III cable with straight-straight connectors
30 cm SATA III cable with down-straight connectors
SMC1m10 10/50
