1.2.1

Options Information

The conga-IC170 is currently available in four variants.
configurations available. Check for the part number that applies to your product. This will tell you what options described in this user's guide
are available on your particular module
Table 1 conga-IC170 Variants
Part-No.
Processor
Intel ® Smart Cache
Max. Turbo Frequency
Processor Graphics
Graphics Max. Dynamic Freq
Memory (DDR4)
LVDS
DisplayPort (DP)
HDMI
Processor TDP (cTDP down)
1.2.2

Optional Accessories

Table 2 Cooling/IO Shield
Accessories
conga-IC97/CSA
conga-IC97/Retention Frame
conga-IC97/CSP
conga-IC170 IO Shield - Standard Size
conga-IC170 IO Shield - Thin Size
Table 3 Memory Modules
Memory Modules
DDR4-SODIMM-2400 (4GB)
DDR4-SODIMM-2400 (8GB)
DDR4-SODIMM-2400 (16GB)
Copyright © 2016 congatec AG
This user's guide describes all of these variants. The table below show the different
052700 052701
Intel Core™ i5-6300U 2.4 GHz Intel
® ®
Dual Core™ Dual Core™
3 MByte 3 MByte
3.0 GHz N.A
Intel HD Graphics 520 (GT2) Intel
® ®
1.0 GHz 1.0 GHz
2133 MT/s dual channel 2133 MT/s dual channel
Yes Yes
Yes Yes
Via DP to HDMI cable adapter Via DP to HDMI cable adapter
15 (7.5) W 15 (7.5) W
Part No. Description
052252 12V active cooling solution with Thin Mini-ITX height (compatible with conga-IC170)
052254 Retention frame for conga-IC97/CSA (compatible with conga-IC170)
052260 Passive cooling solution with Thin Mini-ITX height (compatible with conga-IC170)
052751 IO shield for conga-IC170 Mini-ITX height
052752 IO shield for conga-IC170 with Thin Mini-ITX height
Part No. Description
068790 Certified 4 GB DDR4 SODIMM memory module with 2400 MT/s
068791 Certified 8 GB DDR4 SODIMM memory module with 2400 MT/s
068792 Certified 16 GB DDR4 SODIMM memory module with 2400 MT/s
052702
Core™ i3-6100U 2.3 GHz Intel Celeron™ 3955U 2.0 GHz
®
Dual Core™
2 MByte
N.A
HD Graphics 520 (GT2) Intel HD graphics 510 (GT1)
®
900 MHz
2133 MT/s dual channel
Yes
Yes
Via DP to HDMI cable adapter
15 (10) W
ICSLm13.indd
052703
Intel Core™ i7-6600U 2.6 GHz
®
Dual Core™
4 MByte
3.4 GHz
Intel HD Graphics 520 (GT2)
®
1.0 GHz
2133 MT/s dual channel
Yes
Yes
Via DP to HDMI cable adapter
15 (7.5) W
11/95
