Options Information

The conga-PA5 is currently available in 9 variants.
configurations available. Check for the Part No. that applies to your product. This will tell you what options described in this user's guide are
available on your particular module.
Table 1 conga-PA5 Commercial Variants
Part-No.
Intel Processor
L2 Cache
Burst Frequency
Onboard Memory
Processor Graphics
Graphics Base / Burst 500 MHz / 650 MHz
LVDS
DDI
Processor TDP (Max)
Table 2 conga-PA5 Industrial Variants
Part-No.
Intel Processor
L2 Cache
Burst Frequency
Onboard Memory
Processor Graphics
Graphics Base / Burst 500 MHz / 650 MHz
LVDS
DDI
Processor TDP (Max)
Copyright © 2017 congatec AG
048100 048101
Atom™ x7-E3950 Atom™ x5-E3940
Quad Core 1.6 GHz Quad Core 1.60 GHz
2 MB 2 MB
2.00 GHz 1.80 GHz
8 GB 2400 MT/s 4 GB 2133 MT/s
Intel ® HD Graphics 505 Intel ® HD Graphics 500 Intel
400 MHz / 600 MHz
Single / Dual 18 / 24bit Single / Dual 18 / 24bit Single / Dual 18 / 24bit Single / Dual 18 / 24bit Single / Dual 18 / 24bit Single / Dual 18 / 24bit
DisplayPort++ DisplayPort++
12 W 9.5 W
048110 048111
Atom™ x7-E3950 Atom™ x5-E3940
Quad Core 1.60 GHz Quad Core 1.60 GHz
2 MB 2 MB
2.00 GHz 1.80 GHz
8 GB 2400 MT/s 4 GB 2133 MT/s
Intel ® HD Graphics 505 Intel ® HD Graphics 500
400 MHz / 600 MHz
Single / Dual 18 / 24bit Single / Dual 18 / 24bit
DisplayPort++ DisplayPort++
12 W 9.5 W
This user's guide describes all of these variants. The tables below show the different
048102 048120
Atom™ x5-E3930 Pentium
Dual Core 1.30 GHz Quad Core 1.10 GHz
2 MB 2 MB
1.80 GHz 2.50 GHz
4 GB 2133 MT/s 8 GB 2400 MT/s
® HD Graphics 500 Intel
400 MHz / 550 MHz 200 MHz / 750 MHz
DisplayPort++ DisplayPort++
6.5 W 6 W
04812
Atom™ x5-E3930
Dual Core 1.30 GHz
2 MB
1.80 GHz
4 GB 2133 MT/s
Intel ® HD Graphics 500
400 MHz / 550 MHz
Single / Dual 18 / 24bit
DisplayPort++
6.5 W
PA50m01
048121
® N4200 Celeron ® N3350
Dual Core 1.10 GHz
1 MB
2.40 GHz
4 GB 2400 MT/s
® HD Graphics 505 Intel ® HD Graphics 500 Intel
200 MHz / 650 MHz
DisplayPort++
6 W
048123
Pentium ® N4200
Quad Core 1.10 GHz
2 MB
2.50 GHz
4 GB 2400 MT/s
® HD Graphics 505
200 MHz / 750 MHz
DisplayPort++
6 W
