1
Review the Oracle FS System power requirements.
2
Review the information about power cabling and verify that your PDUs
meet the electrical requirements.
3
Disconnect the power cable from the factory designated anchor point and
secure it to an anchor point behind the PDU, midway in the rack.
4
Route the power cables securely. Routing and securing power cables
within the rack is essential to prevent damage due to loose or overhanging
cables. Routing the cables is also required for easy access and servicing of
the Oracle FS System components (Pilots, Controllers, and Drive
Enclosures).
Note: The power cables connecting the Oracle FS System to the main
power supply in the data center are routed based on whether the source of
the main power supply in the data center is located overhead or located at
the floor level.
5
Secure the power cables to the rack such that they do not restrict the
removal of any other component.
Important: Do not turn on any power circuits until the installation is
complete and all network cables are in place.
CAUTION: Apply power to the Pilot only after all appropriate Ethernet
cables and the CAT6a Ethernet cables are connected between the two
Pilots.
Single-Phase PDU Cabling
The following table lists the specifications for single-phase power distribution
units (PDUs) in various countries:
Table 24: Single-phase PDUs
Single-phase
PDUs
Rack location
Inlet circuits
AC voltage
Power
North America, South America,
Japan, and Taiwan
Vertical rack-mounted PDUs that
occupy no rack unit (RU) space.
Each PDU has two 30A (de-rated
to 24A) inlet circuits. The inlet
plug style is NEMA L6-30.
Each PDU supports AC voltage
levels 200 – 240VAC at 50/60Hz.
Each PDU can supply 10KW of
power when both power cables
are connected.
System Power
EMEA
Vertical rack-mounted PDUs
that occupy no rack unit (RU)
space.
Each PDU has two 25A inlet
circuits. The inlet plug style is
IEC309.
Each PDU supports AC voltage
levels from 200 – 240VAC at
50/60Hz.
Each PDU can supply 10KW of
power when both power cables
are connected.
57
