Figure 52: I/O module LEDs

Legend
The following table provides status information on the I/O module LEDs.

Table 35: Drive Enclosure LED status and description (I/O module)

Status
The status is
normal.
An I/O module
fault is present.
The I/O module is
located.
A vital product
data (VPD) error is
present.
The host port is not
connected.
The host port is not
active.
The host port
activity is normal.

Drive LED Indicators

The LED indicators on the Drive Enclosure drives provide power activity status,
locate indicators, and fault conditions of each drive.
The following figures show the drive LEDs for both types of Drive Enclosure.
1 Fault and locate indicator
2 Power and OK indicator
Fault and locate
indicator (amber)
Off
On
Flash
Not applicable
Not applicable
Not applicable
Not applicable
Oracle FS System LED Status
3 Host port activity indicator
Power and OK
indicator (green)
On
Off
On
Flash
Not applicable
Not applicable
Not applicable
Host port activity
(green)
Not applicable
Not applicable
Not applicable
Not applicable
Off
On
Flashing
