Table 5: DE2-24P Drive Enclosure dimensions and weight

Attribute Value
Height 3.46 in (8.79 cm); 2U
Weight (with 55 lb (24.9 kg)
drives)
Width Width across mounting flange: 19 in (48.26 cm)
Width across body of enclosure: 17.44 in (44.29 cm)
Depth 24.8 in (62.99 cm)

Table 6: DE2-24C Drive Enclosure dimensions and weight

Attribute Value
Height 6.92 in (17.57 cm); 4U
Weight (with 110 lb (49.89 kg)
drives)
Width Width across mounting flange: 19 in (48.26 cm)
Width across body of enclosure: 17.44 in (44.29 cm)
Depth 24.8 in (62.99 cm)
Power Characteristics

Table 7: Pilot power characteristics

Power Value
characteristic
Frequency 50–60Hz
AC voltage 100–240V
Maximum 314 VA
power
consumption for
both nodes
Current draw 1.42A, 208V
for both nodes
Oracle FS Systems: Installation Overview
21
