Pilot Fan LED Indicators

Each Pilot fan module has one bicolored LED. These LEDs are on the Pilot side
wall next to the fan modules and are visible when the top cover fan door is open.

Table 39: Pilot fan LED status and description

LED
Fan
Status
LED

Pilot Port LED Indicators

The Pilot has LED indicators for Network Management ports and the Ethernet
ports.
Network Management Port Status LEDs
The Pilot has one 10/100BASE-T Ethernet management domain interface, labeled
NET MGT. There are two LEDs on this port. These indicators are visible from the
back of the Pilot.

Table 40: Network management port LED status and description

LED
Link
speed
Activity Top
Ethernet Port Status LEDs
The Pilot has four Ethernet ports (NET 3, NET 2, NET 1, NET 0). There are two
LEDs on each port. These LEDs are visible from the back of the Pilot.
Icon LED color Status
NONE Bicolored:
Amber/
Green
Location LED Status
color
Top left Amber
or
Green
Green
right
Amber – There is a fan fault.
•
Green – Fan is properly installed and
•
operating correctly. No fan errors detected.
Amber on - 10BASE-T link
•
Green on - 100BASE-T link
•
Off - No link or link down
•
Flashing - No function
•
On - No function
•
Off - No activity
•
Flashing - Packet activity
•
Oracle FS System LED Status
