The following figure shows an example of the cables routed through a Controller
CMA.

Figure 20: Controller cables routed through the CMA

Legend
1 Back of a Controller
2 Controller cables
The following figure shows an example of the cables routed through a Pilot
CMA.

Figure 21: Pilot cables routed through the CMA

Oracle FS System Cables
3 CMA
53
