Table 10: Low voltage dual phase PDU for Oracle Flash Storage Systems
(continued)
Low Voltage
Outlet groups for each PDU
PDU power cord length

Table 11: Low voltage three-phase PDU for Oracle Flash Storage Systems

Low Voltage
kVA size
Marketing part number
Manufacturing part number
Phase
Voltage input
Number of input cords and plug type
Number of data center receptacles and
type
Maximum input current for each cord
Outlet receptacles (number/type)
Outlet groups for each PDU
PDU power cord length
Oracle FS Systems: Installation Overview
2Ph (2W + ground)
6
2 meters (6.6 feet)
PDU power cords are 4 m (13 ft) long, but
only 2 m (6.6 ft) are usable outside of the
cabinet.
3Ph (3W + ground)
15 kVA
7104979
7051909
3
No grounded neutral conductors are
provided in the input cords.
3Ph [(3W+ground)] 208Vac, 50/60 Hz,
maximum. 40A per phase
Can be connected to Ph-Ph input sources in
the range of 190V – 220V AC (nominal)
1x IEC 309, 60A (Hubbell C460P9W or
equivalent)
1x IEC 309, 60A (Hubbell 460R9S or
equivalent)
40A
42/C13 (seven for each outlet group)
6/C19 (one for each outlet group)
6
2 meters (6.6 feet)
PDU power cords are 4 meters (13 feet)
long, but sections are connected for internal
routing in the rack.
25
