Dual In-Line Memory Module (DIMM)

1. Turn OFF the power switch.
[1]
[1]
[2]
[1]
5. To reinstall, reverse the order of removal.
2. Remove the rear center cover [1].
A2YFF2C027DA
3. Loosen the screw [1], and remove
A2YFF2C028DA
4. Pull the DIMM [1] toward you about
A2YFF2C038DA
7. OTHER MAINTENANCE ITEM
the metal plate [2].
45 degrees, and remove it.
