Konica Minolta bizhub C25
Specification & Installation Guide

bizhub C25 Specifications

Type
Desktop Full Color Printer/Copier/
Scanner/Fax
Continuous
Simplex
Copy/Print Speeds
Monochrome 25
(ppm)
Color
8.5" x 11" (Letter)
Duplex
Monochrome 25
Color
Copy Productivity
Monochrome
Copy Speed 1:1
(600 x 300 dpi)
(ppm)
Color
8.5" x 11" (Letter)
(600 x 300 dpi)
Color
(300 x 300 dpi)
Print Method
Electrostatic laser, tandem, indirect
Photoconductor
OPC (Organic Photo Conductor)
Copying System
Laser electrostatic copy method
Developing System Mono-component SMT
Fusing System
Belt fusing system
Resolution
Scanning: 600 x 600 dpi
Printing: 600 x 600 dpi
Output Size
Bypass Tray (Standard):
4" x 6", 5.5" x 8.5", 8.5" x 11", 8.5" x 14"
Tray 2 (Standard):
4" x 6", 5.5" x 8.5", 8.5" x 11"
Tray 3 (Optional): 8.5" x 11", 8.5" x 14"
Paper Capacity
Bypass Tray (Standard): 100 sheets
Tray 2 (Standard): 250 sheets
Tray 3 (Optional): 500 sheets
Total: 850 sheets (total with options)
Multiple Copy
1-99
Image Loss
Copy: Max. 4.0 mm
for Top/bottom/right/left edge
Print: Max. 4.2 mm
for Top/bottom/right/left edge
Warm Up Time
38 sec. or less (May vary depending
on the operating environment and usage.)
Monthly Duty Cycle 120,000 pages.
Maximum monthly copy/print volume
supported under standard vendor supplied
service. Defines the upper end of the
expected customer volume for the device.
Customers should consider multiple
machines if average monthly volume
approached duty cycle on continual basis.
Plain Paper
Thick Paper
12.5
25
12.5
Plain Paper
Thick Paper
12.5
25
12.5
20
10
20
Copy
Copy Gradation
256 Color shades per pixel (8-bit)
Copy Memory
128 MB (Shared with copy, scan and fax)
Original Type
Sheets, Books, Objects
Automatic
35 page capacity/Simplex Scanning
Document Feeder
(Manual Duplex)
Maximum
ADF: 8.5" x 14"
Original Size
Flatbed: 8.5" x 11"
First Copy Time
17/12 sec. (Fastest mode: 16.0/11.0 sec.)
(Color/B&W)
Copy Magnification Fixed Same Magnification: 1:1±1.0% or less
Scaling Up: 1:1.15/1.41/2.00/4.00
Scaling Down: 1:0.86/0.70/0.50/0.25
Zoom: Flatbed: 25 to 400%, 1% increments
ADF: 25 to 400%, 1% increments
Copy Features
Inch and metric system
Manual Duplex Document
Duplex Copy
Sort Copy
2-in-1 Copy
4-in-1 Copy
Flatbed N-in-1
ID Card Copy
Repeat
Poster
Original Type
Text, Text/photo, Photo
Density
Auto/Manual (7 levels)

Print Controller

Type
Emperon Print Controller v 5.5
Processor/Speed
MV78100/800 MHz
Print Memory
256 MB (Standard)
512 MB Print Memory Upgrade (Option)
768 MB Total with Options
Hard Disk Drive
Optional 40 GB SATA hard drive adds a
significant amount of features including
secure print, proof-then-print, print & hold,
job storing, user authentication for printing,
XPS emulation, direct printing (PDF, TIFF,
JPEG, XPS), downloading fonts/profiles/
overlays, collating and PDF direct print.
Print Resolution
600 x 600 dpi x 3 bit
Page Description
PostScript 3 (3016) Emulation, PCL5e/c/
Language
PCL6 (XL3.0) Emulation, XPS Emulation,
PDF Direct Printing, JPEG/TIFF/XPS
Direct Print
Protocols
TCP/IP, IPX/SPX, EtherTalk, Netware 4.x,
5.x, 6, IPP 1.1, POP3, LDAP, SNMP v1, v2,
v3, HTTP/HTTPS, IPv6, DPWS (WSD), IPP
over SSL, IPSec (IPv6), Bonjour, NTP, SSL/
TLS, Dynamic DNS, LLTD, IEEE802.1X, FTP,
SLP, LLMNR, DHCP, BootP, DHCPv6
04/2011
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the bizhub C25 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Konica Minolta bizhub C25

  • Page 1: Print Controller

    Konica Minolta bizhub C25 Specification & Installation Guide 04/2011 bizhub C25 Specifications Copy Type Desktop Full Color Printer/Copier/ Copy Gradation 256 Color shades per pixel (8-bit) Scanner/Fax Copy Memory 128 MB (Shared with copy, scan and fax) Continuous Simplex Plain Paper...
  • Page 2: Paper Handling

    Konica Minolta bizhub C25 Specification & Installation Guide bizhub C25 Specifications continued PCL6: Supported OS Windows XP/XP 64bit/Server 2003/ Fax Line/Mode PSTN (Public Switch Telephone Network), PBX (Private Branch Exchange), Super G3 Server 2003 64bit/Vista/Vista 64bit/Server 2008/Server 2008 64bit/7/7 64bit...
  • Page 3 Konica Minolta bizhub C25 Specification & Installation Guide bizhub C25 Specifications continued Paper Matrix Type/weight Print/USB Memory to print/copy Tray 2 (250 sheets) Tray 1 Bypass tray Tray 3 (Option) Duplex (100 sheets) (500 sheets) Plain paper (60-90 gsm) Recycle paper (60-90 gsm)
  • Page 4: Space Requirements

    Konica Minolta bizhub C25 Specification & Installation Guide Space Requirements Environmental Considerations Temperature 50°F to 86°F To ensure easy operation, consumable replacement Humidity 15% to 85% and maintenance, adhere to the recommended space requirements detailed below. Acoustic Noise Copying: <53.5 dB Printing: <52.5 dB...
  • Page 5: Paper Weight Conversion Chart

    Konica Minolta bizhub C25 Specification & Installation Guide Paper Considerations Paper Size Conversion Chart Paper Letter Letter R Legal Tabloid Statement Statement R Measurement 8.5" x 11" 11" x 8.5" 8.5" x 14" 11" x 17" 5.5" x 8.5" 8.5" x 5.5" Paper Weight Conversion Chart Caliper Bond Offset Cover Index Point...
  • Page 6 Konica Minolta bizhub C25 Specification & Installation Guide How to build a bizhub C25 System (from start to finish) How to Build a bizhub C25 System (from start to finish) 04/2011 Step 1: Base Unit bizhub C25 Full Color Printer/Copier/Scanner/Fax Includes Emperon PS/PCL Controller, Automatic Duplex Unit, 256 MB Print Memory, 2k yield Starter Toner Cartridges...
  • Page 7: Base Unit

    A steel cabinet with door and shelf inside, and locking casters. This matches the bizhub InfoLine look of the bizhub C25. This copy desk allows the bizhub C25 to be placed away from the desktop on a copy SCD-25 Copy Desk TBD* A steel cabinet with door and shelf inside, and locking casters.
