Robotis Comprehensive Kit Robot Series Quick Start Manual page 94

Comprehensive Kit Robot Series
Body
Step 4
※Insert nuts
N1
: 4pcs
※Insert nuts
N1 : 4pcs
Right Wheel
Step 5
※Attach nut stickers :
Make sure nuts do not
come off.
※Assemble 2 sets.
※Assemble taking note of the inserted location
of nuts .
S1
: 12pcs
3
motor
※Insert nuts
ADAPTOR-CM5
Sticker
N1 : 2pcs
F3 : 3pcs
motor
N1 : 12pcs
S1
: 4pcs
F3
: 2pcs
S1 : 8pcs
Left Wheel
Step 6
※Attach nut stickers :
Make sure nuts do not
come off.
※Assemble 2 sets.
※Assemble taking note of the inserted location
of nuts .
: 3pcs
F3
S1
: 12pcs
1
2
motor
※Insert nuts
94
: 4pcs
N1
Step 3
Sticker
: 2pcs
N1
N1 : 12pcs
4
motor
