Comprehensive Kit Robot Series
◎ How to download Motion Data
The filename extension of Motion Data is "mtn." The users download this program whenever it
is necessary..
Connect PC and CM-5
Select Management(M)=>Robot Motion (R)menu.
Select "Write to Robot" and open
the motion data file you want.
※ If problem occurs in this progress above formality, refre to "Download
Troubleshooting"from page"2-1-2. Downloading Robot Programs".
Serial Cable
Close the download dialog box.
Turn on
ON
Execute Behavior Control Programmer
(If it has done previously,not necessary)
Download is completed.
When download is complete,
progress bar color changes.
15
of CM-5.
Power
OFF
