Comprehensive Kit Robot Series
２-２-７. Melody Car
Let's build a melody car that chimes and moves in a direction corresponding to a button
(1) Necessary parts
1 2 3
motor motor motor motor
AX-12 × 4
※Nuts, screws, and cables shown below are the same as the actual size. Place and measure the parts
against the below illustration to choose the correct assembly part.
N1 × 48
S1 × 48
S2 × 16
4
AX-S1 × 1
× 6
F3 F13
CM-5
× 1
× 4 × 4
F14
48
ADAPTOR-CM5
× 1
Sticker × 10
CABLE-6
CABLE-14
× 2
CABLE-10
× 2
× 1
