２-４-２. Puppy
Let's build a puppy that performs various cute tricks.
(1) Necessary parts
1 4
17
~
motor motor
motor
AX-12 ×15
F1 ×1 F2 ×9
※Nuts, screws, and cables shown below are the same as the actual size. Place and measure the parts
against the below illustration to choose the correct assembly part.
N1 ×156
S1 ×188
S3 ×12
S6 ×16
S-B ×10
AX-S1
×1
F3 ×15
F6 ×1
BU ×10 WA ×10
158
CM-5
×1
ADAPTOR-CM5
F7 ×6
SP1 ×4
CABLE-6
CABLE-10
Expansion
×1 PCB
F9 ×2 F10 ×18
×3
×4
×6
CABLE-14
CABLE-18 ×4
×1
