２-２-１１. Attacking Duck
Let's build a duck robot that attack with a beak when the sensor detects an object.
(1) Necessary parts
1 2 3
CM-5
ADAPTOR-CM5
motor motor motor
AX-12 × 3 AX-S1
× 1 × 1 × 1
F1 × 1 F3 × 5 F9 × 1 BU × 2
F2 × 1 F11 × 1
WA × 2
※Nuts, screws, and cables shown below are the same as the actual size. Place and measure the parts
against the below illustration to choose the correct assembly part.
N1 × 40
CABLE-10
× 2
S1 × 56
CABLE-14 × 2
S-B × 2
