２-３-５. Turtle
Let's build a turtle that senses and avoids an obstacle.
(1) Necessary parts
1 8
~
motor motor
AX-12 × 8
F1 × 4
F3 × 10
※ Nuts, screws, and cables shown below are the same as the actual size. Place and measure the parts
against the below illustration to choose the correct assembly part.
N1 × 64
S-B × 4
AX-S1
× 1
BU × 4 WA × 4
× 96
S1
118
CM-5
× 1
Sticker ×8
ADAPTOR-CM5
× 1
× 2
CABLE-6
CABLE-10 × 1
× 2
CABLE-14
× 1
CABLE-18
× 3
CABLE-20
