Crossing Gate - Robotis Comprehensive Kit Robot Series Quick Start Manual

Comprehensive Kit Robot Series
２-２-１. Crossing Gate
Let's build a crossing gate that opens and closes with a button.
(1) Necessary parts
1
CM-5 ADAPTOR-CM5
motor
AX-12 × 1
× 1 × 1
F2 × 1 × 5 × 1 BU × 1 WA × 1
F3 F6
※Nuts, screws, and cables shown below are the same as the actual size. Place and measure the parts
against the below illustration to choose the correct assembly part.
S2 × 8
× 24 × 20
N1 S1 S-B × 1
CABLE-14 × 1
20
