２-３-３. Robot Flower
Let's build a robot that blooms a flower when the light is shone and that moves petals when
there is a sound.
(1) Necessary parts
1 6
~
motor motor
AX-12 × 6
F1 × 3 F2 × 3
※Nuts, screws, and cables shown below are the same as the actual size. Place and measure the parts
against the below illustration to choose the correct assembly part.
N1 × 68
S1 × 92
S-B × 6
AX-S1
× 1
F3 × 9 × 3
F9
105
CM-5
× 1
BU × 6 WA × 6
CABLE-6
CABLE-10
ADAPTOR-CM5
× 1
× 1
× 3
CABLE-20 × 3
