King Spider - Robotis Comprehensive Kit Robot Series Quick Start Manual

Comprehensive Kit Robot Series
２-４-３. King Spider
Let's build a king spider that moves around and attacks when it detects an object.
(1) Necessary parts
1 18
~
motor
motor
AX-12 ×18
F1 ×6
F2 ×6
※Nuts, screws, and cables shown below are the same as the actual size. Place and measure the parts
against the below illustration to choose the correct assembly part.
N1 ×206
S1 ×256
S2 ×18
S3 ×4
S-B ×18
AX-S1
×1
F4 ×6
F3 ×20
169
CM-5
×1
ADAPTOR-CM5
F6 ×6
F7 ×6
Expansion
×1 PCB
BU ×18 WA ×18
CABLE-6 ×6
×4
CABLE-10
CABLE-14 ×6
CABLE-18 ×4
×1
SP1 ×4
