Comprehensive Kit's Parts - Robotis Comprehensive Kit Robot Series Quick Start Manual

Comprehensive Kit Robot Series
３-５. Comprehensive kit's parts
1
18
~
motor motor
AX-12 ×18
F1 ×10
F2 ×10
F8 ×3
F9 ×5
F15 ×1 F16 ×1
SMPS
※Nuts, screws, and cables shown below are the same as the actual size. Place and measure the parts
against the below illustration to choose the correct assembly part.
N1 ×400
N2 ×10
S1 ×400
S2 ×20
S3 ×20
S4 ×20
S5 ×20
S6 ×20
S-B ×30
AX-S1
×1
F3 ×20
F10 ×20
BU ×20 WA ×20
Sereal Cable
S7 ×20
S8 ×20
CM-5
(Battery included)
×1
F4 ×6 F5 ×6
F11 ×2 F12 ×2
SP1 ×4 SP2 ×4
Quick Start
197
Expansion
ADAPTOR-CM5 ×1
F6 ×12
F13 ×4
Sticker ×32
CD
×6
CABLE-6
×4
CABLE-10
CABLE-14
CABLE-18
CABLE-20
×1
PCB
F7 ×6
F14 ×4
Fuse ×1
×6
×4
×5
