２-３-４. Fawn
Let's build a fawn that sits and looks around when nothing is detected but that follows an object
when it detects an object.
(1) Necessary parts
1 7
~
motor motor
AX-12 × 7
F1 × 3 F2 × 2
※ Nuts, screws, and cables shown below are the same as the actual size. Place and measure the parts
against the below illustration to choose the correct assembly part.
N1 × 100
S1 × 128
S-B × 6
AX-S1
× 1
F3 × 15 F4 × 2
111
CM-5
× 1
F9 × 1
CABLE-6
CABLE-10
CABLE-14
CABLE-18
CABLE-20
ADAPTOR-CM5
× 1
BU × 6 WA × 6
× 1
× 2
× 2
× 1
× 2
