Timeclock Operation

Set Up Afterhours Mode

Main menu 1. Enter programming mode (see page 15).
2. Use the Master buttons to highlight "Timeclock", press the
Timeclock
Timeclock
OK button to accept, then use the Master buttons to highlight
Scene setup
"Afterhours setup", and press the OK button to accept.
3. Use the Master buttons to highlight either "Enabled", "Follow",
or "Disabled". (See the previous page for explanations of the
Timeclock
three modes.) Press the OK button to accept.
4. If "enabled" was selected, use the Master buttons to highlight
Holiday
the values for each setting; press the OK button to accept
Afterhours setup
each and continue to the next.
5. The info screen will confirm that your afterhours settings have
been saved.
Afterhours
6. Exit programming mode (see page 15).
Enabled
Warn time
Settings screens
for enabled mode:
Saved
®
1
Flash count
3
5 minutes
2 3 4 5 6
Delay time
15 minutes
GRAFIK Eye
OK
Afterhours
Scene 5

End Afterhours Mode

To interrupt the afterhours mode and return
to the programmed timeclock event,
1. Enter programming
mode (see page 15),
select "Timeclock,"
End afterhours
and select "End
afterhours". Press the
OK button to accept.
2. The info screen
will confirm that
afterhours mode is
ended.
3. Exit programming
mode (see page 15).
QS Installation and Operation Guide 42
®
Master
buttons
OK
button
