Occupancy Sensor Setup

Label an Occupancy Sensor (optional)

1. Enter programming mode (see page 15).
Main menu
2. Use the Master buttons to highlight "Sensor Setup" and press
Zone Setup
the OK button to accept.
Sensor Setup
3. Use the Master buttons to highlight "Occupancy" and press
the OK button to accept.
4. Use the Master buttons to highlight "Labels" and press the
Sensor Setup
OK button to accept.
5. Use the Master buttons to display an occupancy sensor to
Daylight
label and press OK to select.
Occupancy
6. Use the Master buttons to scroll through the characters
(lowercase and uppercase letters, plus numbers 0 through 9).
The character you are currently changing will be underlined
Occ Sensor
on the screen. Press OK to select the character you want,
then repeat for all available characters. Choose a space (no
Labels
character) and press OK for any remaining characters. Press
Settings
the OK button to accept.
7. The info screen will confirm that your name has been saved.
8. Exit programming mode (see page 15).
Sensor x/y
SN: xxxx-xxxx
Source: RF 1/n
Label sensor x/y
1 / 11
A
1: A
Saved
Saved
®
1 2 3 4 5 6
GRAFIK Eye QS Installation and Operation Guide 26
®
Master
buttons
OK
OK
button
Timeclock
(back) button
