Daylight Sensor Setup

Assign Sensors

This step allows you to assign sensors to each zone, with one daylight sensor per
zone connected to the GRAFIK Eye
more than one zone.
Select Sensors
Daylight Sensor
1. Use the Master buttons to highlight "Setup" and press the
Setup
OK button to accept. Available sensors will be displayed.
2. You can assign one sensor per zone, and a sensor can be
Calibrate
assigned to more than one zone. Use the Master buttons to
scroll through the sensors until the one you wish to assign or
unassign is highlighted, and press the OK button to select it.
3. Use the zone raise and lower buttons for each zone to assign
Saved
Searching
or unassign the sensor to that zone. The zone raise button
assigns the displayed sensor, and the zone lower button
unassigns it. Repeat for all desired sensors and press OK. A
screen will verify your settings have been saved.
Sensor x/y
4. Calibrate sensors: Press the Timeclock (back) button to return
to the Daylight Sensor screen. Use the Master buttons to
SN: xxxx-xxxx:
select the desired group and press the OK button to accept.
Source: RF
5. Use the Master buttons to select the desired zone and press
the OK button to accept.
6. Put any wireless Radio PowrSavr
Sensor x/y
associated with the desired zones into Calibrate Mode: Press
and hold the "Cal" button for 6 seconds until the sensor
Select
flashes.
Zones
7. Use the Master buttons to select the desired light level for the
zone, and press the OK button to accept. Repeat for all zone
levels you wish to calibrate. Press the OK button to accept.
8. Exit programming mode (see page 15).
Note: If wireless sensors are not found, verify that they are
associated correctly (see page 28).
Daylight Sensor
Setup
3 seconds
Calibrate
®
1
QS control unit. Sensors can be assigned to
®
Sensor Name Adjust Light
More light
Zone 1
Less light
2 3 4 5 6
daylight sensors
TM
Saved
Saved
GRAFIK Eye
OK
1 9 2 10 3 11 4 12
1 9 2 10 3 11 4
Zone raise
Zone lower
QS Installation and Operation Guide 29
®
Master
buttons
OK
button
Timeclock
(back) button
5 13 6 14 7 15 8 16
12 5 13 6 14
Cal
button
