PANEL DESCRIPTION

■ Function display

Push [MENU] to toggle the function display menu.
• The set of functions assigned to the function switches
change according to the selected menu and operat-
ing mode.
• In the DV mode, M3 (
after selecting menu 2.
• In the DR mode, the D1 and D2 displays can be se-
lected.
M1 (Menu 1) display
D
(Mode: SSB)
AGC DUP
(Mode: SSB-D)
AGC DUP
(Mode: CW)
AGC DUP
(Mode: RTTY)
AGC DUP
(Mode: AM)
AGC DUP
(Mode: FM)
AGC DUP
(Mode: DV)
AGC DUP
19
menu 3) display can be selected
COMP TBW SCP
1 ⁄ 4 SCP
KEY
1 ⁄ 4 SCP
RTTY
1 ⁄ 4 SCP
SCP
AFC TON SCP
AFC DSQ SCP
Push to select the functions displayed in the display
above switches ([F-1] to [F-5])
• Functions vary, depending on the operating mode.
M2 (Menu 2) display
D
SCAN MEM SWR
M3 (Menu 3) display
D
(Mode: DV)
CS CD R>CS
D1 display
D
(Mode: DV) (Only when "
CS CD R>CS
D2 display
D
(Mode: DV) (Only when "
SCAN SEL AFC
TCON VSC
UR DSET
" is displayed.)
UR DSET
" is displayed.)
DSQ TCON
