■ Linear amplifier connections

D Connecting the IC-PW1/PW1EURO

To an
antenna [ACC1]
[ANT]
IC-PW1/EURO
AC outlet
(Non-European versions : 100–120/200–240 V
European version
Remote control cable (supplied with the IC-PW1/PW1EURO)
ACC cable (supplied with the IC-PW1/PW1EURO)
[REMOTE]
[INPUT1]
[INPUT2]
[GND]
: 230 V)
INSTALLATION AND CONNECTIONS
7-pin side
Coaxial cable
( supplied with the IC-PW1/
PW1EURO)
OPC-599
Coaxial cable*
[ANT1] [ANT2]
[GND]
Transceiver
Ground
* Purchase separately, and connect
to [INPUT2], if necessary.
[ACC] [REMOTE]
