Icom i9100 Instruction Manual page 196

18
CONTROL COMMAND
D Command table (continued)
Cmd. Sub cmd.
1A 05 0054 0000 to
0055
0056
0057
0058
0059
0060
0061
0062
0063
0064
0065
0066 00 to 10 Send/read COMP level
0067 see p. 192 Send/read SSB RX HPF/LPF setting
0068 00 to 10 Send/read SSB RX Tone (Bass) level
0069 00 to 10 Send/read SSB RX Tone (Treble) level
0070 00 to 10 Send/read SSB TX Tone (Bass) level
0071 00 to 10 Send/read SSB TX Tone (Treble) level
0072 see p. 192 Send/read SSB TX bandwidth for WIDE
187
Data Description
Send/read USB modulation level
(0000=0% to 0255=100%)
0255
00 Send/read 9600 bps mode OFF
01 Send/read 9600 bps mode ON
00 Send/read MIC selection for the modula-
tion input during DATA mode OFF
01 Send/read ACC selection for the modula-
tion input during DATA mode OFF
02 Send/read MIC+ACC selection for the
modulation input during DATA mode OFF
03 Send/read USB selection for the modula-
tion input during DATA mode OFF
00 Send/read MIC selection for the modula-
tion input during DATA mode ON
01 Send/read ACC selection for the modula-
tion input during DATA mode ON
02 Send/read MIC+ACC selection for the
modulation input during DATA mode ON
03 Send/read USB selection for the modula-
tion input during DATA mode ON
00 Send/read CI-V transceive OFF
01 Send/read CI-V transceive ON
00 Send/read no function selection for
"USB2" (COM port) function
Send/read RTTY selection for "USB2"
01
(COM port) function
02 Send/read DVdat selection for "USB2"
(COM port) function
00 Send/read no function selection for
[DATA1] function
Send/read RTTY selection for [DATA1]
01
function
02 Send/read DVdat selection for [DATA1]
function
00 Send/read OFF selection for GPS Out
01 Send/read DATA->USB2 selection for
GPS Out
00 Send/read 4800 bps selection for GPS
position data transmission speed of
[DATA1]
01 Send/read 9600 bps selection for GPS
position data transmission speed of
[DATA1]
Send/read 300 bps selection for RTTY
00
Decode Baud rate
Send/read 1200 bps selection for RTTY
01
Decode Baud rate
Send/read 4800 bps selection for RTTY
02
Decode Baud rate
Send/read 9600 bps selection for RTTY
03
Decode Baud rate
Send/read 19200 bps selection for RTTY
04
Decode Baud rate
00 Send/read Calibration marker OFF
01 Send/read Calibration marker ON
0000 to Send/read reference frequency
(0000=0% to 0255=100%)
0255
(00= Minimum to 10= Maximum)
(00=–5 to 10=+5)
(00=–5 to 10=+5)
(00=–5 to 10=+5)
(00=–5 to 10=+5)
Data
Cmd. Sub cmd.
1A 05 0073 see p. 192 Send/read SSB TX bandwidth for MID
0074 see p. 192 Send/read SSB TX bandwidth for NAR-
ROW
0075 see p. 192 Send/read AM RX HPF/LPF setting
0076 00 to 10 Send/read AM RX tone (Bass) level
(00=–5 to 10=+5)
0077 00 to 10 Send/read AM RX Tone (Treble) level
(00=–5 to 10=+5)
0078 00 to 10 Send/read AM TX tone (Bass) level
(00=–5 to 10=+5)
0079 00 to 10 Send/read AM TX Tone (Treble) level
(00=–5 to 10=+5)
0080 see p. 192 Send/read FM RX HPF/LPF setting
0081 00 to 10 Send/read FM RX tone (Bass) level
(00=–5 to 10=+5)
0082 00 to 10 Send/read FM RX Tone (Treble) level
(00=–5 to 10=+5)
0083 00 to 10 Send/read FM TX tone (Bass) level
(00=–5 to 10=+5)
0084 00 to 10 Send/read FM TX Tone (Treble) level
(00=–5 to 10=+5)
0085 see p. 192 Send/read DV RX HPF/LPF setting
0086 00 to 10 Send/read DV RX tone (Bass) level
(00=–5 to 10=+5)
0087 00 to 10 Send/read DV RX Tone (Treble) level
(00=–5 to 10=+5)
0088 00 to 10 Send/read DV TX tone (Bass) level
(00=–5 to 10=+5)
0089 00 to 10 Send/read DV TX Tone (Treble) level
(00=–5 to 10=+5)
0090 see p. 192 Send/read CW RX HPF/LPF setting
0091 see p. 192 Send/read RTTY RX HPF/LPF setting
0092 00 Send/read Normal selection for contest
number style
Send/read "190 → ANO" selection for con-
01
test number style
Send/read "190 → ANT" selection for con-
02
test number style
Send/read "90 → NO" selection for con-
03
test number style
Send/read "90 → NT" selection for contest
04
number style
0093 01 Send/read M1 selection for count up trig-
ger channel
02 Send/read M2 selection for count up trig-
ger channel
03 Send/read M3 selection for count up trig-
ger channel
04 Send/read M4 selection for count up trig-
ger channel
0094 0001 to Send/read present number
(0001=1 to 9999=9999)
9999
0095 0000 to Send/read CW sidetone gain
(0000=0% to 0255=100%)
0255
0096 00 Send/read CW sidetone gain limit OFF
01 Send/read CW sidetone gain limit ON
0097 01 to 60 Send/read CW keyer repeat time
(01=1 sec. to 60=60 sec.)
0098 00 Send/read Normal selection for message
display
01 Send/read Message selection for mes-
sage display
0099 28 to 45 Send/read CW keyer dot/dash ratio
(28=1:1:2.8 to 45=1:1:4.5)
0100 00 Send/read 2 msec. selection for CW Rise time
01 Send/read 4 msec. selection for CW Rise time
02 Send/read 6 msec. selection for CW Rise time
03 Send/read 8 msec. selection for CW Rise time
Description
