■ Function Display (INFO screen)

L When you switch the main screen between the INFO, the Plotter, and the Highway screens,
push [DISP].
Information area
Position and Software Key area
Time area
D Position and Time area
POSITION AREA
The current position is displayed when
valid GPS data is received, or you manually
enter your position.
Indicator
Displayed when a GPS
NO
antenna is not connected or
POSITION your position has not been
manually entered.
Blinks every 2 seconds instead
of your position when:
• The GPS position is invalid.
• 4 hours have passed since
??
you manually entered your
position.
L After 23.5 hours have
passed, "NO POSITION"
will be displayed.
Channel
area
Description
PANEL DESCRIPTION
TIME AREA
The current time is displayed when valid
GPS data is received, or manually enter
the time.
Indicator
Displayed when a GPS
antenna is not connected
NO TIME
or the time has not been
manually entered.
Displayed when the offset
Local
time is set.
Displayed when the time was
Manual
manually entered.
Displayed when the RMC,
GGA, GLL, or GNS sentences
are received from the built-in
UTC
GPS receiver, an external
NMEA 0183, or external
NMEA 2000 sentence source.
Blinks every 2 seconds
instead of the time when:
• The GPS current time is
invalid.
• 4 hours have passed since
??
you manually entered the
time.
L After 23.5 hours have
passed, "NO TIME" will be
displayed.
• Position and Time area also displays your
vessel's SOG (Speed Over Ground) and
COG (Course Over Ground).
L SOG or COG may not be displayed,
depending on the NMEA 0183 or the
NMEA 2000 data.
